18650 Cylindrical Cell Electric Crimping Machine

Name: 18650 Cylindrical Cell Electric Crimping Machine
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-CDF-18
Price: 1,500.00 USD
Availability: InStock

Nome da marca:	TICO
Número do modelo:	STC-CDF-18
MOQ:	1 Piece
preço:	Negociável
Tempo de entrega:	5~10 working days
Condições de pagamento:	T/T,

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Place of Origin:

Shen Zhen, China

Crimping stroke:

25mm

Crimping pressure:

Max. 1000kg adjustable, digital display

Dimension:

L300 * W200 * H570mm

Weight:

40kg

Packaging Details:

Standard export wooden packing

Supply Ability:

15 sets per month

Descrição do produto

Cylindrical Cell Electric Crimping Machine

Brief Introduction

The machine is used for various of cylindrical cell case crimping, such as 18650, 26650, AA, AAA, etc. The sealing process involves two stages: a primary sealing and a secondary sealing. 18650 crimping die as standard, others crimping die is optional. It is capable of sample making for laboratory battery research and development and can also be used for factory trial-production.

Key Features

● Electric-driven, ensuring no vibration during battery crimping.

● Through the primary and secondary crimping, the crimping edge is flat, good air tightness, high dimensional accuracy, high efficiency, excellent consistency.

● Adopted flexible pressure buffer mechanism to ensure pressure equalization.

● Precise die design ensures accurate and reliable crimping and forming, firm steel structure design is stable and safe to use.

● HIM touch screen operation for technical parameters setting easily, with high automation.

● Small size, easy to operate, can be placed in the glove box operation.

● Attractive appearance, easy maintenance and operation, forming precisely.

Technical Parameters

Model	STC-CDF-18
Voltage	AC 220V±10%, 50Hz
Power	100W
Crimping die	18650 crimping die as standard, others crimping die is optional
Crimping stroke	25mm
Crimping pressure	Max. 1000kg adjustable, digital display
Material of structural components	High-strength chrome steel with environmental plating and spraying treatment, it have a good rust prevention
Dimension	L300 * W200 * H570mm
Weight	40kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer ?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.

2. Do you accept customized product ?

A : Yes. Most of our products can be customzied to meet different requirements.

3. Will you provide test video before dispatch ?

A : Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service ?

A : Yes, we can dispatch professional engineer for on-site installation service.
